2094-PRS3 Product datasheet

2094-PRS3 Functional Description

The Kinetix 6000 Multi-axis Servo Drives Allen-Bradley 2094-PRS3 is a slim, three-axis power rail integral to the Kinetix 6000 motion control system. It is engineered for versatility, seamlessly supporting both 200V and 400V class servo drives from families including Kinetix 6200 and Kinetix 6500. This compatibility ensures it can serve as a unified platform for diverse motor control applications within a single cabinet.

A defining feature of the 2094-PRS3 Power Rail Allen-Bradley is its structured slot configuration, which includes a dedicated converter slot for an Integrated Axis Module (IAM) and two additional inverter slots. These slots can accommodate various modules like axis or shunt modules, allowing for a customized and scalable drive system. The physical design of this unit is compact, measuring just one inch in depth to optimize valuable panel space.

The installation process for the ALLEN BRADLEY SER A 3 Axis Slim Power Rail 2094-PRS3 is streamlined for reliability and safety. It mounts directly to a prepared subpanel and includes a braided grounding strap to ensure proper bonding. Furthermore, protective covers are provided for the power rail connectors, safeguarding the sensitive electronics from damage and contamination during and after installation.

Ultimately, the primary advantage of the 2094-PRS3 Allen-Bradley Kinetix Servo Drive is its ability to simplify complex multi-axis system architecture. By consolidating power distribution and module mounting, it significantly reduces wiring complexity and cabinet footprint. This integrated approach, championed by the Power Rail 2094-PRS3 Allen-Bradley , enhances overall system organization, improves maintainability, and contributes to a more robust motion control solution.
