2094-BC02-M02-M    Product datasheet

2094-BC02-M02-M    Functional Description

The Integrated Axis Module 2094-BC02-M02-M  Allen Bradley is a Kinetix 6200/6500 Integrated Axis Module (IAM) designed for high-performance motion control applications. Operating at 360-480V AC, this module combines a 15 kW/23A converter and 6.6 kW/14.6A inverter in a compact design. It features an integrated Safe Torque-Off (STO) function, ensuring compliance with industrial safety standards while eliminating the need for external safety relays.

The Kinetix 6000 Multi-axis Servo Drives 2094-BC02-M02-M supports seamless integration with Kinetix 600M drive-motor systems and offers solid-state motor short-circuit protection. When paired with proper branch circuit protection, it can handle up to 200,000A (fused) or 65,000A (circuit breaker) fault currents. Recommended fuses include Bussmann FNQ-R-10 (10A) for control input and FWJ-40A for DC bus power, ensuring reliable operation.

With advanced safety features, the AB 2094-BC02-M02-M Integrated Axis Power Module enables smooth transitions between Safe Speed Monitor, Safe Maximum Speed, and STO modes. Its embedded diagnostics provide real-time fault detection, reducing downtime. The Allen Bradley 2094-BC02-M02-M Integrated Axis Module's EtherNet/IP and SERCOS interface compatibility allows flexible networking with Kinetix 6000 systems, supporting easy upgrades.

The 2094-BC02-M02-M ROCKWELL Kinetix 6000 Multi-axis Servo Drives optimizes energy efficiency with 44W (converter) and 72W (inverter) heat dissipation at partial loads. Its modular design simplifies maintenance, reduces wiring complexity, and minimizes spare parts inventory. Ideal for industrial automation, this IAM enhances productivity with Safe Direction Monitoring, Zero Speed Control, and Door Monitoring, making it a robust solution for modern motion control systems.
