ABB SDCS-PIN-48 COAT 3ADT220090R0043 Pulse Transformation Board

Inquiry now

SDCS-PIN-48 COAT 3ADT220090R0043 Product datasheet

Model number:	SDCS-PIN-48 COAT 3ADT220090R0043	Module Type：	Pulse Transformation Board
Manufacture:	ABB	Condition：	Brand New
Range of Product:	Advant OCS/800xA	Lead time：	In Stock
Weight:	0.3 kg	HS CODE：	8537101190
Dimension:	27x10x2.3cm	MOQ:	1
Product Origin:	SWEDEN	System：	DCS
Discontinued on:	Active	Communication Service:	Ethernet router

SDCS-PIN-48 COAT 3ADT220090R0043 Functional Description

The ABB SDCS-PIN-48 COAT 3ADT220090R0043 Pulse Transformation Board operates within a versatile 24V DC power range, supporting both differential (±12V) and single-ended (0-24V) configurations while maintaining low power consumption under 5W. This coated pin contact module forms a critical interface in automation systems where stable power distribution is essential. The ABB SDCS-PIN-48 COAT 3ADT220090R0043 PDF delivers output voltages compatible with both TTL (0-5V) and HTL (0-24V) logic levels, ensuring broad device compatibility.

Similar to the described thyristor monitoring system, the Advant OCS/800xA SDCS-PIN-48 COAT 3ADT220090R0043 incorporates protective measures against environmental stressors. Its specialized coating (indicated by "COAT" in 3ADT220090R0043) provides additional insulation and corrosion resistance, complementing the module's electrical isolation properties. The ABB SDCS-PIN-48 COAT 3ADT220090R0043 maintains signal integrity even in conditions where temperature fluctuations affect nearby power components.

The Pulse Transformation Board SDCS-PIN-48 COAT ABB supports systems with integrated PTC thermistor detection, mirroring the safety philosophy of the described thyristor units. While not containing thermistors itself, this module reliably transmits temperature alarm signals from monitored components, with its 48-contact design (highlighted in SDCS-PIN-48) enabling comprehensive system diagnostics.

The SDCS-PIN-48 COAT 3ADT220090R0043 ABB meets rigorous industrial standards for both performance and durability. The module's design anticipates common cooling system variations and electrical loads, making it particularly valuable for automation applications requiring consistent signal transmission under changing operational conditions.
