3BHE016842R0101 UAD144 A101 Overview

The 3BHE016842R0101 UAD144 A101 ABB ELECTICAL DRIVES is an AC 800PEC controller board with 16 analog inputs, 1GB memory, and includes a USB hardware key with a license for engineering configuration tools.

Features and benefits

Core Control Function: Serves as the primary processor board for the AC 800PEC controller, enabling reliable process logic execution.

Integrated Licensing: Includes a USB hardware key that provides one license for the Engineering Configuration Tool (ECT), simplifying software setup and access.

High-Performance Analog Inputs: Features 16 channels of high-resolution (±10V, 16-bit) analog input for precise signal acquisition.

Robust Memory Capacity: Equipped with 1 GB of DDR3 memory to support complex control applications and data handling.

Enhanced Electrical Safety: Offers 2500 V DC isolation between power and earth, ensuring protection in demanding industrial environments.

Wide Operational Range: Designed for reliable performance in temperatures from -20°C to +60°C and high humidity conditions.

FAQ

Q1: What is the main function of this ABB unit?

A1: It is the main controller board (UAD144 A101) for the AC 800PEC M process controller, responsible for executing control logic and managing I/O.

Q2: What is included with this controller board regarding software access?

A2: It includes a USB hardware key that provides one license for the Engineering Configuration Tool (ECT), required for system programming and configuration.

Q3: How many analog input channels does it support and what is their specification?

A3: It provides 16 high-resolution analog input channels, each capable of accepting a ±10V signal with 16-bit resolution.

Q4: What are the key environmental specifications for its operation?

A4: The board is designed to operate reliably in a wide temperature range from -20°C to +60°C and at 5-95% relative humidity (non-condensing).

Q5: What safety feature protects the system's power supply?

A5: It incorporates 2500 V DC isolation between the power supply and earth ground, enhancing system safety and noise immunity.
