ABB 23WT22 Voice Frequency Telegraphy Device

Inquiry now

23WT22 Product datasheet

Model number:	23WT22	Module Type：	Voice Frequency Telegraphy Device
Manufacture:	ABB	Condition：	Brand New
Range of Product:	ABB	Lead time：	In Stock
Weight:	0.9 kg	HS CODE：	8537101190
Dimension:	19x12x13.5cm	MOQ:	1
Product Origin:	SWEDEN	System：	DCS
Discontinued on:	Active	Communication Service:	Ethernet router

23WT22 Functional Description

The ABB 23WT22 Voice Frequency Telegraphy Device is a high-performance Voice Frequency Telegraphy (VFT) terminal designed for reliable supervisory control and data transmission over high-voltage power lines (110–500 kV). This Swedish-made device operates across a wide frequency range (30–500 kHz) with flexible channel spacing (120/240 Hz) and supports multiple shift ranges (±30/±60/±120 Hz). It offers configurable modulation options including Frequency Shift Keying (FSK) and Amplitude Modulation (AM), accommodating data rates from 50 to 600 baud. Its compact design (19×12×13.5cm) and lightweight construction (0.9kg) ensure easy integration into existing power line communication systems.

Engineered for robust performance, the 23WT22 ABB in stock features a 48/60V DC power supply with low consumption (<15 W) and operates in extreme temperatures (-20°C to +65°C). The device provides 1–4 independent telegraphy channels with carrier coupling through Capacitor Couplers (CC) and Line Traps (LT). With an impressive 10 kV isolation between field and logic circuits, the ABB 23WT22 Voice frequency telegraph equipment ensures safe operation in high-voltage environments. Its adjustable attenuation compensation (0–40 dB) and -30 dBm operating threshold enable reliable signal transmission even over long distances.

The FSK modem 23WT22 supports multiple interface options including 600Ω balanced audio (4-wire) and dry contact control signals (24–220V DC). This flexibility makes it suitable for various teleprotection and SCADA applications. The device's carrier frequencies (300–3400 Hz) and baud rate options (50/200 Bd) allow customization for different network requirements. As part of ABB's power line communication portfolio, the ABB 23WT22 demonstrates exceptional immunity to power line noise and interference, ensuring data integrity in challenging electrical environments.

Widely used in energy transmission systems, the VOICE FREQUENCY TELEGRAPHY DEVICE 23WT22 provides critical communication links for grid operators. Its humidity tolerance (5–95% non-condensing) and rugged construction make it ideal for substation installations. It maintains ABB's reputation for quality, offering maintenance-free operation and long service life. This VFT terminal represents an optimal solution for utilities requiring secure, real-time data exchange across high-voltage networks, combining advanced technology with proven reliability in power line carrier communications.
