NFLP121-S00 Overview

The Communication Module Yokogawa NFLP121-S00 is a PROFIBUS-DP master communication module for FCN systems, enabling seamless I/O data exchange and device diagnostics with DP-V0/V1 compatibility.

Specifications

• Function: PROFIBUS-DP master communication module for FCN systems.

• Compatibility: Supports DP-V0 and DP-V1 specification versions.

• Interface: Single-port EIA-RS485 connection with D-sub 9-pin female connector.

• Dimensions: Compact size of 3.2 x 14.1 x 13 cm and lightweight at 0.3 kg.

• Performance: Maximum transmission distance of 1.2 km/segment at 9600 bps.

• Electrical: Requires 5V DC power with maximum current consumption of 700 mA.

FAQ

Q1: What is the primary function of the Yokogawa NFLP121-S00?

A1: It serves as a PROFIBUS-DP master communication module for Yokogawa FCN systems, enabling seamless control and data exchange with slave devices.

Q2: Which PROFIBUS-DP specifications does this module support?

A2: It supports both DP-V0 and DP-V1 specifications for flexible integration and advanced diagnostic capabilities.

Q3: What is the maximum communication distance of the NFLP121-S00?

A3: It supports a maximum transmission distance of 1.2 km per segment at 9600 bps via its RS-485 interface.

Q4: Does the module provide electrical isolation for signal integrity?

A4: Yes, it features isolation between the signal and system to ensure reliable operation in industrial environments.

Q5: How is the module physically connected to a PROFIBUS network?

A5: It uses a standard D-sub 9-pin female connector for EIA-RS485-compliant PROFIBUS-DP communication.
