CP401-10 S1 Overview

The Yokogawa CP401-10 S1 Modules DCS CPU Module is a 24 VDC CPU Controller module. It forms the central node of the FFCS system, supporting up to eight I/O modules and enabling dual-redundant processor configurations for high system availability.

Application

• System Core: It serves as the primary CPU node in the FFCS control system.

• I/O Expansion: Supports connecting up to eight I/O modules for local signal processing.

• System Extension: Allows connection to a maximum of three additional extension nodes, including direct-coupling and remote nodes.

• Dual-Redundant Control: Enables high-availability system configurations using the Pair & Spare method.

• Fault Tolerance: Facilitates seamless control transfer during processor failure without system shutdown.

• Bus Integration: Uses ESB and ER bus interface modules (EC401/SB401/EB401) for node communication and expansion.

FAQ

Q1: What is the main function of the Yokogawa CP401-10 S1 module?

A1: It serves as a 24 VDC CPU controller and processor module, forming the core node of the FFCS control system.

Q2: How many I/O modules can be connected to the CP401-10 S1?

A2: It supports the installation of up to eight I/O modules directly in its CPU node.

Q3: Can the CP401-10 S1 be used in redundant configurations?

A3: Yes, it supports a dual-redundant configuration using the field-proven Pair & Spare method for high availability.

Q4: How does the module achieve fault tolerance?

A4: Its dual-redundant design allows for seamless transfer of control during a failure, preventing any momentary system shutdown.

Q5: Is the Yokogawa CP401-10 S1 still in production?

A5: No, according to the provided information, this product model has been discontinued by the manufacturer.
