6ES7155-5MU00-0CN0 Overview

The Siemens 6ES7517-3HP00-0AB0 high-performance central processing unit is a high-performance S7-1500H CPU with 2 MB program and 8 MB data memory, dual PROFINET interfaces, and hardware synchronization for redundancy. It supports flexible configuration via TIA Portal and ensures reliable operation in critical industrial applications.

Siemens 6ES7155-5MU00-0CN0 features

Multi-Fieldbus Interface

Supports EtherNet/IP and Modbus TCP for flexible network integration.

High-Performance Operation

Enables isochronous IRT mode with 250 µs cycles for precise, real-time control.

Robust & Modular Design

Supports up to 30 I/O modules and hot-swappable configuration with an active backplane.

Enhanced System Security

Includes PROFINET Security Class 1 for secure network communication.

Redundancy & Reliability

Supports MRP, MRPD, and S2 redundancy for maximum system availability.

Streamlined Engineering

Fully configurable in TIA Portal (from V20) and via GSD file for easy integration.

FAQ

Q1: What fieldbus protocols does this interface module support?

A: It supports EtherNet/IP and Modbus TCP for flexible multi-network integration.

Q2: Does it support real-time industrial communication?

A: Yes, it offers isochronous IRT mode with cycle times as low as 250 µs for precise real-time control.

Q3: Can I expand I/O capacity with this module?

A: Yes, it supports up to 30 I/O modules and allows local coupling with up to 6 coupling modules.

Q4: Is hot-swapping of modules possible during operation?

A: Yes, with an active backplane bus, modules can be swapped without stopping the system.

Q5: What engineering tools can be used to configure this module?

A: It is fully configurable in STEP 7 TIA Portal (from V20) and via PROFINET GSD file (GSDML V2.45).
