Schneider Electric MC-4/11/10/400 HW: E0R603 SW:V00.12.XX AC Pac Drive

Inquiry now

MC-4/11/10/400 HW: E0R603 SW:V00.12.XX Product datasheet

Model number:	MC-4/11/10/400 HW: E0R603 SW:V00.12.XX	Module Type：	AC Pac Drive
Manufacture:	Schneider Electric	Condition：	Brand New
Range of Product:	Schneider Electric	Lead time：	In Stock
Weight:	3.54 kg	HS CODE：	8537101190
Dimension:	6.8x24.5x31cm	MOQ:	1
Product Origin:	France	System：	PLC
Discontinued on:	active	Communication Service:	Ethernet router

MC-4/11/10/400 HW: E0R603 SW:V00.12.XX Functional Description

Schneider Electric MC-4/11/10/400 HW: E0R603 SW:V00.12.XX AC Pac Drive plays a vital role in the PacDrive™ automation system, serving as a high-performance communication module for packaging machinery control. This robust DIN-rail mounted device enables seamless integration between the PacDrive Controller and MC-4 servo drives, supporting the system's 40-axis motion coordination capability through its advanced protocol conversion functions.

As part of Schneider's industrial automation solution, the Programmable Controller Module HW: E0R603 SW:V00.12.XX ensures reliable data exchange via SERCOS real-time bus, maintaining the system's 4MBaud communication rate for precise servo control. Its SW:V00.12.XX firmware provides enhanced compatibility with both PROFIBUS-DP and CANopen fieldbus standards, critical for packaging machine synchronization.

The Schneider Electric MC-4/11/10/400 HW: E0R603 SW:V00.12.XX PDF module extends system connectivity with dual serial interfaces and Ethernet support, enabling remote diagnostics via TCP/IP while maintaining immunity to electromagnetic interference. When integrated with the PacDrive™ Controller, it facilitates real-time monitoring of all servo axes through the EPAS-4 programming environment per IEC 61131-3 standards.

This particular HW:E0R603 version demonstrates Schneider's commitment to backward compatibility, as it seamlessly interfaces with legacy systems while supporting modern OPC data exchange. The MC-4/11/10/400 Drives by SCHNEIDER ELECTRIC's rugged design and SW:V00.12.XX software optimization make it indispensable for high-speed packaging applications requiring precision motion control and network flexibility.
