Schneider ATV930D22N4 Variable Speed Drive

Inquiry now

ATV930D22N4 Product datasheet

Model number:	ATV930D22N4	Module Type：	Variable Speed Drive
Manufacture:	Schneider Electric	Condition：	Brand New
Range of Product:	Schneider Electric	Lead time：	In Stock
Weight:	1.9 kg	HS CODE：	8537101190
Dimension:	27.9x21.6x6.3cm	MOQ:	1
Product Origin:	France	System：	PLC
Discontinued on:	active	Communication Service:	Ethernet router

ATV930D22N4 Functional Description

The Schneider Variable Speed Drive ATV930D22N4 is a 22kW variable speed drive from the Altivar 900 series, designed for robust industrial applications requiring high performance. This specific model operates on a 400/480V supply and comes equipped with an integrated braking unit, making it suitable for controlling three-phase synchronous and asynchronous motors with precision. It also features an IP21 rating, providing basic protection against solid objects and water droplets, which is essential for many manufacturing environments.

A key feature of the ATV930D22N4 Schneider IN STOCK is its compatibility with an advanced graphic display option, which significantly enhances user interaction. This optional display, requiring FLASH V1.1IE29 or higher firmware, enables the presentation of extensive text information beyond the standard terminal's capabilities. When this graphic interface is activated, dedicated keys on the display unit—including STOP/RESET, RUN, and a multifunction jog dial—can be used to control the Schneider ATV930D22N4 directly, providing flexible operational control.

The jog dial on the compatible graphic display offers intuitive navigation for the Variable Speed Drive ATV930D22N4, allowing operators to save parameter values, enter selected menus, increment or decrement values, and adjust speed references through simple press-and-rotate actions. It is critically important to note that only the specific VW3A1101 display module is compatible with this drive series. Using incompatible displays such as those designed for ATV21 or ATV12 models could result in loss of control, creating serious safety hazards.

Manufactured in France, the Drive ATV930D22N4 Schneider represents European engineering quality and reliability. This drive is particularly valuable for complex industrial processes where precise motor control, advanced connectivity, and comprehensive safety features are paramount. The combination of its powerful performance characteristics and sophisticated control options makes the SCHNEIDER ATV930D22N4 an excellent choice for demanding applications across various industrial sectors.
