Honeywell MLC-DR32H/DC Power Supply Module

Inquiry now

MLC-DR32H/DC Product datasheet

Model number:	MLC-DR32H/DC	Module Type：	Power Supply Module
Manufacture:	HONEYWELL	Condition：	Brand New
Range of Product:	HONEYWELL	Lead time：	In Stock
Weight:	0.4kg	HS CODE：	8537101190
Dimension:	7x14x14.5cm	MOQ:	1
Product Origin:	USA	System：	DCS
Discontinued on:	active	Communication Service:	Ethernet router

MLC-DR32H/DC Functional Description

The Relay Digital Output Module Honeywell MLC-DR32H/DC is a comprehensive 32-point digital I/O module designed for the MasterLogic ML50 PLC system, combining 16 digital inputs and 16 relay outputs in a single compact unit. This integrated module operates on a 24V DC power supply and provides 660mA/3A capacity, making it suitable for various industrial control applications. The MLC-DR32H/DC BASE MODULE Honeywell features photo-coupler insulation and accepts input voltages from DC 20.4 to 28.8V with less than 5% ripple rate, ensuring reliable operation in electrically noisy environments.

The input section of the Honeywell MLC-DR32H/DC Power Supply Module demonstrates precise voltage sensitivity with ON operation at DC19V/3mA or more and OFF operation at DC6V/1mA or less. The module incorporates 5.6 kΩ input resistance (2.7 kΩ for points P00-P07) and maintains excellent insulation characteristics, rated at AC 560Vrms for 3 cycles and insulation resistance of 10 MΩ or more when tested with a megger. These specifications ensure both operational accuracy and electrical safety in industrial settings.

The output section of the Honeywell MLC-DR32H/DC PDF utilizes relay contacts capable of handling diverse load types, providing flexibility for controlling various field devices. The module's common method configuration uses 16 points per COM, simplifying wiring and installation while maintaining system organization. Weighing 1.32 kg and designed for 100-240V AC power supply operation, the Power Supply Module MLC-DR32H/DC combines robust construction with practical functionality for industrial automation requirements.

Through its combination of reliable digital input processing and versatile relay output capabilities, the Honeywell MLC-DR32H/DC serves as a fundamental component in industrial control systems. This module exemplifies Honeywell's commitment to manufacturing PLC components that meet the rigorous demands of modern industrial automation, providing engineers with a reliable solution for machine control, process automation, and other applications where precise digital I/O control is essential for operational success and system integrity.
