IS400JPDHG1A Overview

The General Electric MK VIeS IS400JPDHG1A  is a high-density power distribution board for the Mark Vle control system. It efficiently distributes 28V DC power to up to 24 I/O packs and 3 Ethernet switches, featuring daisy-chain capability and PTC fuse protection.

Features and benefits

High-Density Power Distribution: Efficiently powers up to 24 Mark Vle I/O packs and 3 Ethernet switches from a single 28V DC source.

Scalable Daisy-Chain Design: Allows connection of multiple boards to support systems requiring more than 24 I/O packs.

Triple Modular Redundancy (TMR): Features three separate 28V DC input feeds (R, S, T) for enhanced system reliability.

Integrated Circuit Protection: Each I/O pack output is safeguarded by a Positive Temperature Coefficient (PTC) fuse device.

Compact DIN-Rail Mounting: Space-saving design optimized for high-density control panel installations.

Wide Operating Range: Functions reliably in temperatures from -30°C to 65°C for robust industrial performance.

FAQ

Q1: What is the core function of General Electric IS400JPDHG1A?

A1: It is a high-density power distribution board supplying 28V DC to 24 I/O packs and 3 Ethernet switches.

Q2: Which GE series does IS400JPDHG1A belong to?

A2: It is part of the GE Mark VIe series for distributed control systems.

Q3: How is IS400JPDHG1A mounted?

A3: It supports DIN-rail mounting for space-saving and easy installation in control cabinets.

Q4: Does IS400JPDHG1A have overcurrent protection?

A4: Yes, each I/O output circuit is protected by a positive temperature coefficient fuse.

Q5: Can IS400JPDHG1A be expanded for more devices?

A5: Yes, it allows daisy-chaining with additional boards to power more I/O packs.
