IS210AEDBH4A Product datasheet
|
Model number: |
IS210AEDBH4A |
|
Module Type： |
Bridge Interface Board |
|
Manufacture: |
GE |
|
Condition： |
Brand New |
|
Range of Product: |
Mark VIE |
|
Lead time： |
In Stock |
|
Weight: |
0.4 kg |
|
HS CODE： |
8537101190 |
|
Dimension: |
4x18.6x26.1cm |
|
MOQ: |
1 |
|
Product Origin: |
USA |
|
System： |
DCS |
|
Discontinued on: |
Active |
|
Communication Service: |
Ethernet router |
IS210AEDBH4A Functional Description
The General Electric IS210AEDBH4A Bridge Interface Board is a specialized Bridge Interface Board designed for integration within GE's Mark VI turbine control systems. As part of the Speedtronic series, this board plays a crucial role in managing both gas and steam turbines, ensuring efficient and reliable operation. Its design accommodates various system configurations, including simplex and triple modular redundancy, catering to the specific needs of different turbine setups.
Constructed with a conformal coating, the GE IS210AEDBH4A Mark VIe is protected against environmental factors such as moisture and contaminants, enhancing its durability in industrial settings. The board features multiple transformers with a BIL rating of 12KV to 15KV and a switching frequency ranging from 10KHz to 500KHz, highlighting its capability to handle high-voltage applications. Additionally, it is populated with over 180 integrated circuits, reflecting its complex and robust design.
In terms of connectivity, the IS210AEDBH4A Bridge Interface Board GE includes various connectors on its front surface, such as right-angled cable connectors and multiple header connectors, facilitating seamless integration with existing systems. These features ensure that the board can be easily incorporated into the Mark VI control architecture, maintaining system integrity and performance.
Overall, the General Electric IS210AEDBH4A PDF stands out as a vital component within the Mark VI control system, offering advanced features and reliable performance. Its design and specifications make it well-suited for demanding industrial applications, contributing to the efficient operation of turbine systems.
If you have other request contact our team to get customized service
Call +86 18159889985 to be connected with our Manager Stella
Email to sales6@apterpower.com get your best quotation
For the quick assistance message us on WhatsApp at +86 18159889985 now!
|
