IC695CPU315-BB Product datasheet

IC695CPU315-BB Functional Description

The CPU Module IC695CPU315-BB General Electric is a high-performance RX3i PACSystems processor manufactured by GE Fanuc, now part of Emerson Automation. This powerful Programmable Automation Controller (PAC) features a 1.0 GHz Intel Celeron M processor, 20 MB of user memory, and an additional 20 MB of non-volatile RAM, providing robust processing capabilities for complex automation tasks. The significant memory capacity of the IC695CPU315-BB CPU General Electric CONTROL MODULE supports the handling of large programs and extensive data sets efficiently.

This General Electric IC695CPU315-BB supports up to 512 program blocks, each with a size of 128 KB, and offers substantial I/O memory allocation with 32 kilobits for discrete (%I, %Q) and 32 kilowords for analog (%AI, %AQ) data. For connectivity, the General Electric IC695CPU315-BB Fanuc RX3i Series Central Processing Unit includes two integrated serial ports supporting RS-232 and RS-485 communications, alongside protocols like Serial I/O, Modbus RTU slave, and SNP. It is designed for compatibility with specific RX3i universal backplanes (IC695CHS016, IC695CHS012) via a high-speed PCI interface.

A key feature of the IC695CPU315-BB Rx3i 1GHz CPU W/ 2 Serial Ports is its strong backward compatibility, enabling seamless migration from legacy Series 90-30 systems by supporting those I/O modules and expansion racks. The unit's firmware is field-upgradable, ensuring long-term applicability. It consumes 1.2A at 5V DC and operates effectively within a temperature range of 32 to 140 degrees Fahrenheit.

The reliability of the General Electric IC695CPU315-BB PDF is further underscored by its compliance with PCI standards version 2.2 and the EU RoHS directive. This makes the processor ideal for demanding real-time control applications in industrial automation, providing precise and reliable operation for machinery and processes.
