IC693PWR331 Product datasheet

IC693PWR331 Functional Description

The IC693PWR331 General Electric Power Supply is a high-capacity power supply module engineered for the GE Fanuc Series 90-30 PLC system. It delivers three distinct and regulated output voltages to support various system components: a +5VDC logic supply with a maximum power of 30 watts, a +24VDC relay output rated for 15 watts, and an isolated +24VDC output capable of 20 watts. The robust design of it ensures that the total combined output power is meticulously managed, providing a stable and reliable power foundation for the entire PLC rack, which is critical for demanding industrial applications.

Beyond power generation, the 24 VDC IC693PWR331 General Electric offers advanced integration and diagnostic features. It is equipped with a front-accessible RS485 communication port, enabling seamless configuration via GE Proficy software or a Hand-Held Programmer. For real-time operational status, the module features a comprehensive suite of LED indicators, including PWR, OK, RUN, and BATT. The BATT light is particularly vital as it monitors the health of the onboard battery, which is essential for preserving the PLC's volatile memory during main power interruptions, highlighting the thoughtful design of it.

The physical layout of the GE IC693PWR331 High Capacity prioritizes both serviceability and installation ease. Key components such as the battery connection terminals and the main power wiring strip are conveniently housed on the front panel behind a protective swing door. This centralized front-access design simplifies maintenance and initial setup. Furthermore, the dedicated terminals for the isolated +24VDC output are easily accessible for connecting external devices like sensors and input modules, enhancing the versatility of the General Electric IC693PWR331 in complex control systems.

For installation, the IC693PWR331 GE input High Capacity power supply is designed to be mounted in the leftmost slot of any Series 90-30 baseplate. It operates from a wide input voltage range, supporting both 24 VDC and 48 VDC nominal inputs, which contributes to its adaptability across various industrial environments. To ensure long-term reliability and performance, it is recommended to install the unit in a clean environment, away from excessive dust, contaminants, and heat-generating equipment, thereby maximizing the operational lifespan of this critical power component.
