IC693DNM200-BC Overview

The General Electric Series 90-30 IC693DNM200-BC is a DeviceNet Master Module for GE Series 90-30 PLCs. It features a DeviceNet terminal and RS232 port, supports up to 63 slaves, and handles 255 I/O bytes at rates up to 500Kbps.

Applications

Acts as the master controller in DeviceNet networks for Series 90-30 and RX3i PLCs.

Connects and manages up to 63 DeviceNet slave devices like sensors and drives.

Facilitates high-speed data exchange for industrial automation systems.

Supports flexible I/O connections (Poll, Strobe, Cyclic, COS) for process control.

Enables centralized monitoring and control of distributed field devices.

Suitable for applications requiring real-time data transfer at up to 500Kbps rates.

FAQ

Q1: What is the main function of the General Electric IC693DNM200-BC module?

A1: It serves as a DeviceNet Master Module for the GE Series 90-30 and PACSystems RX3i PLC platforms, enabling communication with up to 63 slave devices.

Q2: What data transmission rates does the IC693DNM200-BC support?

A2: It supports standard DeviceNet transmission rates: 125K, 250K, and 500K Baud.

Q3: How many I/O connections can be established with this module?

A3: Up to 126 I/O connections can be configured, with two I/O connections assignable per slave device.

Q4: What types of data exchange are supported by the IC693DNM200-BC?

A4: It supports Polled, Strobe, Cyclic, and COS (Change of State) connections, as well as explicit messaging and UCMM.

Q5: Can this module operate as both a master and a slave simultaneously?

A5: Yes, it features a dual-mode capability, allowing it to function as both a DeviceNet master and slave at the same time.
