IC200ETM001 Overview

The General Electric IC200ALG266 15-Point Analog current input module is a 15-channel analog input module designed for current signals. It is certified for use in safety-critical control applications.

Environmental Strength

• Robust Construction: Designed for stable performance in standard industrial environments.

• Reliable Connectivity: Features durable 26-pin and 16-pin connectors for secure expansion links.

• Clear Status Indicators: Integrated LEDs provide visual confirmation of power and communication integrity.

• Secure Mounting: Installs on a DIN rail for stable and vibration-resistant mounting within control panels.

FAQ

Q1: What is the primary function of the IC200ETM001?

A1: It is an expansion connector that allows a VersaMax PLC to connect to up to seven additional I/O racks.

Q2: What type of connector does it use to link to expansion racks?

A2: It uses a 26-pin female connector on its front to connect to an expansion receiver module (ERM).

Q3: What is the purpose of its 16-pin serial port?

A3: The serial port is used to upload firmware updates to a nearby Network Interface Unit (NIU) or CPU.

Q4: How can you tell if the module is powered and communicating?

A4: Two LEDs indicate status: one for 5VDC power from the CPU/NIU, and one (EXP TX) that blinks during active communication with the receiver module.

Q5: Where and how is this module physically installed?

A5: It is mounted on a DIN rail and attaches directly to the left side of the VersaMax CPU unit
