DS200TCDAH1BHE Overview

The Digital I/O Board General Electric DS200TCDAH1BHE is a Digital I/O Board designed for the Mark V turbine control system. It is used in steam, gas, and wind turbines to manage input/output signals as part of GE's Speedtronic automation technology.

Technical Data Summary

 Model: DS200TCDAH1BHE, a Digital I/O Board for the Mark V DS200 series.

Function: Manages digital input/output signals within turbine control systems.

IONET Hardware: Equipped with termination resistors (J2, J3) and ID settings (J4-J6).

Software Integration: Configured via the I/O Configuration Editor in the system's HMI.

Revision: Represents the third product revision of the base TCDA design.

FAQ

Q1: What is the DS200TCDAH1BHE?

A1: It is a Digital I/O (Input/Output) Board designed for the GE Mark V Speedtronic turbine control system.

Q2: What is its primary application?

A2: It is used for digital signal control and management in steam, gas, and wind turbine systems compatible with GE products.

Q3: What are its key IONET hardware features?

A3: It includes IONET termination resistors (J2, J3) and configurable IONET ID settings (J4, J5, J6) for network communication.

Q4: How is the board configured?

A4: It is configured using the I/O Configuration Editor software within the system's Human-Machine Interface (HMI).

Q5: What revision does the "BHE" suffix indicate?

A5: The suffix indicates that this board is the third significant product revision of the original DS200TCDAH1 Digital I/O Board.
