DS200PLIBG2ACA Product datasheet
|
Model number: |
DS200PLIBG2ACA |
|
Module Type： |
Phase Logic Interface Board |
|
Manufacture: |
GE |
|
Condition： |
Brand New |
|
Range of Product: |
Mark Vle |
|
Lead time： |
In Stock |
|
Weight: |
0.32kg |
|
HS CODE： |
8537101190 |
|
Dimension: |
28.6x7x3.2cm |
|
MOQ: |
1 |
|
Product Origin: |
USA |
|
System： |
DCS |
|
Discontinued on: |
Active |
|
Communication Service: |
Ethernet router |
DS200PLIBG2ACA Functional Description
The Mark V Series GE DS200PLIBG2ACA is a Phase Logic Interface Board developed for the Mark V Speedtronic control system, which is widely used in the control of gas and steam turbines. This DS200PLIBG2ACA Phase Logic Interface Board General Electric plays an important role in turbine control applications, particularly when integrated with EX2000 digital regulator systems for brushless excitation. It supports both three-phase and single-phase configurations and can interface with servo valves, making it a versatile component in complex turbine management systems.
As part of the legacy Mark V Series, the DS200PLIBG2ACA GE Automation Control offers robust phase logic functionality. It enables interface communication between batch execution servers and control phase logic, helping to manage state transitions efficiently. The board includes factory-drilled, insulated mounting holes, multiple vertical pin connectors, integrated circuits, resistors, capacitors, LEDs, and diodes—engineered for durability and electrical safety.
The Phase Logic Interface Board DS200PLIBG2ACA General Electric supports input from 3-phase voltage sources, with a voltage range of 0–150V AC and a frequency range of 45–65Hz. Its response time is under two cycles, with ±1% full-scale accuracy and 2500V AC isolation, powered by a +5V DC supply, ensuring dependable performance in mission-critical environments.
Although no longer in production, the Interface Board General Electric DS200PLIBG2ACA remains essential for legacy system support. With three key revisions in its lifecycle, it's crucial to verify compatibility before replacement, as only the earlier revisions are backward-compatible.
