The 2711P-B7C4D1 AB OPERATOR INTERFACE is a 6.5-inch PanelView Plus 700 HMI terminal, featuring both keypad and resistive touchscreen input, Ethernet/RS-232/USB communications, and operates on 24V DC for industrial monitoring and control.

Features and benefits

Compact & Durable: Features a rugged 6.5-inch TFT color display with dual keypad/touch input for reliable operation in industrial settings.

Versatile Connectivity: Includes Ethernet (CIP), RS-232 (DF1), and dual USB ports for flexible communication and peripheral connection.

Extended Backlight Life: Equipped with a CCFL backlight rated for a minimum of 50,000 hours, ensuring long-term visibility.

Robust Construction: Designed for high-duty cycles with keypad and touchscreen rated for 1 million actuations.

Easy Integration: Supports standard 24V DC power and offers configuration tools for quick setup and commissioning.

Legacy Compatibility: Communicates with various Allen-Bradley networks (e.g., DH+, ControlNet) via optional modules, protecting existing investments.

FAQ

Q1: What are the main specifications of the Allen-Bradley 2711P-B7C4D1?

A1: It features a 6.5-inch color TFT display with 640x480 resolution, keypad/touchscreen input, 18-32V DC power supply, and Ethernet/RS-232/USB communication ports.

Q2: How does the 2711P-B7C4D1 communicate with other devices?

A2: It supports industrial communication protocols via its Ethernet port (EtherNet/IP) and RS-232 serial port (DF1 protocol), along with two USB ports for peripherals.

Q3: What input methods are available on this HMI terminal?

A3: It offers dual input options including an embedded keypad (function, numeric, navigation keys) and an analog resistive touchscreen interface.

Q4: What is the typical power requirement for this device?

A4: It operates on 24V DC nominal power (18-32V DC range) with a CCFL backlight rated for 50,000 hours minimum lifespan.

Q5: Can this HMI terminal be integrated with legacy Allen-Bradley systems?

A5: Yes, through its communication ports and optional modules, it can connect with DH-485, DH+, and ControlNet networks for backward compatibility.
