1756-A13 Functional Description

The 1756-A13 1756 chassis Allen-Bradley serves as a fundamental component in ControlLogix systems, providing 13 slots for housing controllers, communication modules, and various I/O cards. This AB high-speed communication path 1756-A13 features a sophisticated backplane that efficiently distributes power and enables high-speed data exchange between installed modules. Its robust construction supports horizontal mounting in industrial enclosures, requiring a minimum cabinet size of 24x30x8 inches for proper installation.

This chassis demonstrates remarkable environmental adaptability, operating reliably across temperature ranges from 0-60°C for Series A/B versions and extending to -25-60°C for Series C models. The Allen-Bradley ControlLogix Standard Chassis 1756-A13 maintains stable performance under challenging conditions, withstanding operational vibration of 2g and shock ratings up to 30g. These characteristics make it suitable for demanding industrial environments where equipment reliability is paramount.

The backplane of the ControlLogix 13 Slots Chassis AB 1756-A13 delivers multiple voltage levels to support diverse module requirements, including 1.2V, 3.3V, 5V, and 24VDC power distribution. With power dissipation rated at 5.4 watts, the chassis ensures stable operation while maintaining efficient energy usage. The open-style enclosure design facilitates proper heat dissipation and allows for straightforward maintenance procedures.

Notable features of the ROCKWELL 1756-A13 ControlLogix 13 Slots Chassis include Removal and Insertion Under Power capability, enabling module maintenance without system shutdown. Electronic keying functionality prevents incorrect module replacement, enhancing system integrity. Compatible with Logix 5560, 5570, and 5580 controller families, this chassis provides a scalable platform for medium to large-scale automation applications, ensuring long-term system reliability and operational efficiency.
