Allen-Bradley 1492-IFM20F-F120A-2 Termination Module

Inquiry now

1492-IFM20F-F120A-2 Product datasheet

Model number:	1492-IFM20F-F120A-2	Module Type：	Termination Module
Manufacture:	Allen-Bradley	Condition：	Brand New
Range of Product:	Allen-Bradley	Lead time：	In Stock
Weight:	0.2 kg	HS CODE：	8537101190
Dimension:	7.6 x7.6x12.7cm	MOQ:	1
Product Origin:	USA	System：	PLC
Discontinued on:	Active	Communication Service:	Ethernet router

1492-IFM20F-F120A-2 Functional Description

The Allen-Bradley 1492-IFM20F-F120A-2 Termination Module is a 20-point fusible digital interface module designed for industrial control systems. This feed-through termination module features 5×20mm fuse clips with 120V AC/DC blown fuse indicators, providing critical circuit protection while allowing each input group to reference different power sources. Its compact design (7.6×7.6×12.7cm) and 0.2kg weight enable efficient panel space utilization.

Rated for 12-24V DC (±10%) input voltage, the 20 Point Feed-Through Termination Module 1492-IFM20F-F120A-2 delivers 3mA @ 24V DC per point with 250V AC isolation between field and logic circuits. The module includes 20 fast-acting fuses (120mA rating) and offers 100mA @ 5V DC backplane current. Its finger-safe design and group-isolated power bus (two groups of 10 terminals) enhance operational safety in industrial environments.

The Fusible Interface Modules AB 1492-IFM20F-F120A-2 requires proper wiring per labeled diagrams, with field-side connections following specified guidelines. While fuse holders are included, 5×20mm fuses must be sourced separately. The module's dual-isolation design supports flexible power sourcing, and its tariff code 8537101190 facilitates global logistics from Xiamen, China.

As part of Rockwell's 1492 system, the ALLEN BRADLEY 1492-IFM20F-F120A-2 Extra TERMINALS ensures reliable signal interfacing in automation panels.The AB 1492-IFM20F-F120A-2 Fusible Interface Modules blown fuse indicators enable quick diagnostics, while extra terminals simplify input expansions. The module's US-origin manufacturing guarantees quality for critical control applications requiring precise current protection and signal conditioning.
