TC513V1 3BSE018405R1 Product datasheet
|
Model number: |
TC513V1 3BSE018405R1 |
|
Module Type： |
Coaxial Modem |
|
Manufacture: |
ABB |
|
Condition： |
Brand New |
|
Range of Product: |
Advant Fieldbus 100 |
|
Lead time： |
In Stock |
|
Weight: |
0.72kg |
|
HS CODE： |
8537101190 |
|
Dimension: |
4.4x15x17.6cm |
|
MOQ: |
1 |
|
Product Origin: |
SWEDEN |
|
System： |
DCS |
|
Discontinued on: |
Active |
|
Communication Service: |
Ethernet router |
TC513V1 3BSE018405R1 Functional Description
The AF100 Twisted pair Coax Modem TC513V1 3BSE018405R1 ABB is a versatile Advant Fieldbus 100 modem designed for industrial communication networks. It supports both twisted pair and coaxial (75 Ω) cables, enabling flexible integration in diverse automation environments. With a 24V DC power supply and rated isolation of 50V, this module ensures reliable data transmission in electrically noisy settings. Its compact dimensions (200 x 150 x 30 mm) and lightweight design (0.725 kg) make it ideal for space-constrained installations.
Engineered for robustness, the High-Performance Industrial-Grade Coax Modem TC513V1 delivers high-speed communication with a data rate of up to 1.5 Mbps. It supports twisted pair cable runs up to 500 meters, minimizing signal degradation in large-scale industrial plants. The module’s low power consumption (<5 W) and compliance with RoHS Directive 2011/65/EU underscore its energy efficiency and environmental safety.
The ABB Avant controller TC513V1 excels in reliability, featuring galvanic isolation and EMC protection to withstand harsh industrial conditions. Its plug-and-play design simplifies deployment in ABB’s Advant Controller 800M systems, reducing downtime during upgrades or maintenance.
As a critical component of Industry 4.0 infrastructure, the TC513V1 3BSE018405R1 ABB DCS Module bridges legacy and modern fieldbus systems. Its SCIP compliance (dddc821c-b4a7-4676-9cf6-48f9e5f3ec72) and WEEE Category 5 certification ensure adherence to global standards, making ABB TC513V1 3BSE018405R1 AF100 Twisted pair Coax Modem a trusted choice for process automation worldwide.
If you have other request contact our team to get customized service
Call +86 18159889985 to be connected with our Manager Stella
Email to sales6@apterpower.com get your best quotation
For the quick assistance message us on WhatsApp at +86 18159889985 now!
|
