T9401 Product datasheet
|
Model number: |
T9401 |
|
Module Type： |
Digital Input Module |
|
Manufacture: |
ICS Triplex |
|
Condition： |
Brand New |
|
Range of Product: |
Trusted TMR System |
|
Lead time： |
In Stock |
|
Weight: |
1.26kg |
|
HS CODE： |
8537101190 |
|
Dimension: |
3x30.2x26.5cm |
|
MOQ: |
1 |
|
Product Origin: |
USA |
|
System： |
PLC |
|
Discontinued on: |
active |
|
Communication Service: |
Ethernet router |
T9401 Functional Description
The ICS Triplex T9401 Digital Input Module is a highly reliable digital input module designed for critical industrial control systems. It operates on a 24 VDC power supply and is built with a fault-tolerant TMR (Triple Modular Redundancy) architecture, which is a core feature of the ICS Triplex T9401, ensuring continuous operation and a high level of safety integrity.
This module is certified for SIL 3 applications, making the 16 Channel Digtial Input 24V DC ICS Triplex T9401 suitable for the most demanding safety-critical functions where failure is not an option. Its robust design includes a wide input voltage range and strong resistance to electrical noise and transients, guaranteeing signal integrity in harsh industrial environments.
The INPUT MODULE DIGITAL T9401 ICS Triplex offers flexible configuration with multiple scan times and features a fail-safe design to prevent spurious operation. All input channels are isolated, enhancing the overall system stability and reliability. These characteristics make the ICS Triplex T9401 an indispensable component for protecting complex machinery.
Ease of installation is another key advantage of the ICS Triplex 8-CHANNEL ISOLATED T9401, as it does not require complex wiring or specialized tools. Ultimately, the integration of the T9401 ICS Triplex In Stock into a control system provides unparalleled availability and safety, making it a trusted choice for high-integrity automation and process safety applications.
If you have other request contact our team to get customized service
Call +86 18159889985 to be connected with our Manager Stella
Email to sales6@apterpower.com get your best quotation
For the quick assistance message us on WhatsApp at +86 18159889985 now!
|
