CC-INWE01 Overview

The Honeywell Control Network Module CC-INWE01 is an unmanaged, ruggedized expansion module designed to integrate L1 safety and process systems, providing up to 12 versatile fiber/copper ports for high-density cabinet solutions in demanding environments.

Features and Benefits

• Flexible Topology: Mode selection switch enables seamless integration with multiple L1 safety and process system configurations.

• High Port Density: Provides up to 12 downlink ports (4 combo + 8 expansion) for demanding cabinet installations.

• Dual Media Support: Features combo fiber/copper ports supporting both single-mode (up to 15 km) and multi-mode (up to 2 km) connections.

• Rugged Design: Operates in -40°C to +70°C environments with HAZLOC compliance for harsh industrial applications.

• Easy Installation: Offers CCA and DIN-rail mounting options with plug-and-play unmanaged network operation.

• Enhanced Security: ISA Secure compliant design ensures reliable communication for critical safety systems.

FAQ

Q1: What is the main function of the Honeywell CC-INWE01?

A1: It is a network expansion module designed to integrate multiple Honeywell L1 devices with process and safety control systems.

Q2: How many ports does the complete module provide?

A2: The main module with the expansion module offers up to 12 downlink ports for high port density solutions.

Q3: What types of communication media does it support?

A3: It supports both copper and fiber optic connections, including single-mode (up to 15 km) and multi-mode (up to 2 km) SFP transceivers.

Q4: Can it operate in harsh industrial environments?

A4: Yes, it is ruggedized to operate from -40°C to +70°C and is suitable for HAZLOC installations.

Q5: Does it require complex configuration?

A5: No, it is an unmanaged network device with a mode selection switch that simplifies setup and limits communication to permissible devices.
