IS200WETAH1ADC Product datasheet

IS200WETAH1ADC Functional Description

The Analog Input Module General Electric IS200WETAH1ADC is a critical terminal board component within GE's Mark VI Speedtronic turbine control system, designed for demanding gas and steam turbine applications. This industrial-grade assembly forms part of GE's final Speedtronic series, featuring robust construction with copper alloy terminals and vibration-resistant design to withstand power plant conditions. The General Electric IS200WETAH1ADC Circuit Board Card operates on 24VDC power across a wide -40°C to +70°C temperature range while maintaining reliable signal integrity for turbine control and monitoring functions.

As a core element of the Mark VI system, the 16-point analog input module IS200WETAH1ADC General Electric interfaces with diagnostic tools and Windows-based HMI through its multiple connection points. The board's DIN-rail mountable design simplifies installation in control cabinets, while its UL/CE certified components ensure compliance with international safety standards. With hazardous area certification, the General Electric IS200WETAH1ADC safely operates in potentially explosive environments common to turbine installations, demonstrating GE's engineering focus on both performance and safety.

The terminal board's architecture includes numerous test points and connectors - including over 45 plugs ranging from 2 to 20 positions - facilitating comprehensive system integration. These connection options allow the Circuit Board Card IS200WETAH1ADC General Electric to interface with various Mark VI subsystems while supporting the platform's advanced diagnostic capabilities. The board's layout strategically positions voltage regulators along three edges, with components including relays, diodes, and integrated circuits carefully arranged for optimal signal flow and thermal management.

Designed for long-term reliability, the Mark VI system GE IS200WETAH1ADC exemplifies GE's legacy in turbine control technology, combining robust electrical performance with maintenance-friendly features. Its construction materials and protective design elements address the specific challenges of power generation environments, from vibration resistance to protection against electrical interference. As part of the Mark VI system, this terminal board continues to support critical turbine operations worldwide, maintaining GE's reputation for durable control solutions in the energy sector.
