IS200AEPAH1ABB Product datasheet
|
Model number: |
IS200AEPAH1ABB |
|
Module Type： |
Optional Auxiliary Board |
|
Manufacture: |
GE |
|
Condition： |
Brand New |
|
Range of Product: |
EX2100 |
|
Lead time： |
In Stock |
|
Weight: |
0.82 kg |
|
HS CODE： |
8537101190 |
|
Dimension: |
33x22.7x5cm |
|
MOQ: |
1 |
|
Product Origin: |
USA |
|
System： |
DCS |
|
Discontinued on: |
Active |
|
Communication Service: |
Ethernet router |
IS200AEPAH1ABB Functional Description
The IS200AEPAH1A GE Printed Circuit Board is a high-performance printed circuit board (PCB) designed for GE's Mark VIe Speedtronic turbine control systems. This critical component serves as an I/O pack processor board, managing input/output signals to ensure precise control of steam and gas turbines. Measuring 13" x 7" and weighing approximately 0.4 kg, the GE Mark VI Auxiliary Board IS200AEPAH1ABB features robust construction for demanding industrial environments.
The General Electric IS200AEPAH1ABB offers 8 analog inputs, 1 analog output, 20 discrete inputs, and 8 relay outputs, providing comprehensive control capabilities. With 13 channels and a temperature rating of 0-60°C, this optional auxiliary board includes integrated circuits, resistors, capacitors, and diagnostic LEDs. Its unique C-shaped metal housing (marked HW1) and multiple vertical connectors (2-20 pins) ensure reliable connectivity in turbine control applications.
When sourcing the IS200AEPAH1A IS200AEPAH1ABB Printed Circuit Board , verify compatibility with existing Mark VIe systems and purchase from authorized suppliers. The board attaches via screw-mounted standoffs and communicates through male pin connectors. Its design includes factory-made plated holes and phone jacks for enhanced functionality. The General Electric IS200AEPAH1ABB is manufactured in the USA and available in stock for immediate deployment.
As a vital component in GE's Drive Control series, the General Electric IS200AEPAH1ABB Auxiliary Board delivers reliable performance in power generation systems. Its advanced signal processing and robust architecture make it indispensable for maintaining turbine efficiency and stability. This board exemplifies GE's commitment to quality in industrial automation and control solutions.
If you have other request contact our team to get customized service
Call +86 18159889985 to be connected with our Manager Stella
Email to sales6@apterpower.com get your best quotation
For the quick assistance message us on WhatsApp at +86 18159889985 now!
|
