DS200UCPBG5AFB Product datasheet
|
Model number: |
DS200UCPBG5AFB |
|
Module Type： |
I/O Engine CPU Board |
|
Manufacture: |
GE |
|
Condition： |
Brand New |
|
Range of Product: |
Mark Vle |
|
Lead time： |
In Stock |
|
Weight: |
0.38kg |
|
HS CODE： |
8537101190 |
|
Dimension: |
25.4x10.2x3.5cm |
|
MOQ: |
1 |
|
Product Origin: |
USA |
|
System： |
DCS |
|
Discontinued on: |
Active |
|
Communication Service: |
Ethernet router |
DS200UCPBG5AFB Functional Description
The DS200UCPBG5AFB General Electric I/O Engine CPU Board is an integral part of the Mark V Turbine Control System, specifically designed as an IO Engine CPU board. It is critical for the processing functions within the Mark V Series, General Electric DS200UCPBG5AFB In Stock is known for its applications in controlling gas and steam turbine systems. This particular model is an updated version of the original DS200UCPBG5, featuring three significant revisions to enhance its performance and reliability.
The CPU Board GE DS200UCPBG5AFB works in conjunction with the AAHA board and is mounted on the STCA board in I/O cores, ensuring seamless integration within the turbine control assembly. It contains a 486DX processor and an ARCNET driver, which enables external communication with operator interfaces for monitoring and control. The CPU board is pivotal in handling all processing capabilities, making it central to the operation of the Mark V Turbine Control System.
As a daughterboard on the UCIA motherboard, the I/O Engine CPU Board General Electric DS200UCPBG5AFB serves as the heart of the control system's communication and processing functions. Its bus connections, specifically the J1 and J3 connectors, link it to the UCIA board, facilitating data transmission and system coordination.
Given its critical role, the PC Board Mark V Ge Turbine Control DS200UCPBG5AFB General Electric continues to be well-supported and remains a key component in legacy turbine systems, ensuring reliable operation and advanced control in industrial applications.
If you have other request contact our team to get customized service
Call +86 18159889985 to be connected with our Manager Stella
Email to sales6@apterpower.com get your best quotation
For the quick assistance message us on WhatsApp at +86 18159889985 now!
|
