ABB SDCS-PIN-4 3ADT314100R1001 PCB Card

Inquiry now

SDCS-PIN-4 3ADT314100R1001 Product datasheet

Model number:	SDCS-PIN-4 3ADT314100R1001	Module Type：	PCB Card
Manufacture:	ABB	Condition：	Brand New
Range of Product:	ABB	Lead time：	In Stock
Weight:	1.22 kg	HS CODE：	8537101190
Dimension:	24x19x5.3cm	MOQ:	1
Product Origin:	SWEDEN	System：	DCS
Discontinued on:	Active	Communication Service:	Ethernet router

SDCS-PIN-4 3ADT314100R1001 Functional Description

The INTERFACE BOARD ABB SDCS-PIN-4 3ADT314100R1001 is a specialized power interface board designed for industrial drive and control systems, serving as a critical component in power conversion and distribution within automation architectures. This module functions as an AC-DC power conversion unit, incorporating advanced rectifier and filter circuits to transform incoming AC voltage into stable, pure DC power for system components. The engineering behind the module specifically addresses electromagnetic interference (EMI) challenges through sophisticated circuit design that suppresses both conducted and radiated interference, ensuring compliance with electromagnetic compatibility standards.

Weighing approximately 0.8 kg, the PCB Card ABB SDCS-PIN-4 3ADT314100R1001 features a compact form factor optimized for integration within control cabinet environments. Although this particular model has been discontinued by the manufacturer, it remains an important legacy component in many operational industrial systems. The design of the module emphasizes reliable power conditioning, with careful attention to transformer design and power element selection to maximize conversion efficiency while minimizing electrical noise generation.

The replacement identifier 3ADT316300R1510 indicates ABB's product evolution path, though the original SDCS-PIN-4 Printed Circuit Board 3ADT314100R1001 ABB continues to be sourced for maintenance and repair operations. Its role in providing clean, regulated power makes the ABB SDCS-PIN-4 (3ADT314100R1001) particularly valuable in sensitive automation applications where power quality directly impacts control accuracy and system reliability. The board's construction reflects industrial-grade standards suitable for demanding manufacturing and process environments.

In application, the SDCS-PIN-4 3ADT314100R1001 DC Drives ABB demonstrates ABB's commitment to robust power management solutions within industrial automation. While newer versions have superseded this model, the technical foundation established by the Power Interface Board ABB SDCS-PIN-4 3ADT314100R1001 continues to influence current power interface designs, highlighting its historical significance in the development of reliable industrial control power systems.
