ABB SDCS-CON-H01 3ADT320000R1501 Control Circuit Board

Inquiry now

SDCS-CON-H01 3ADT320000R1501 Product datasheet

Model number:	SDCS-CON-H01 3ADT320000R1501	Module Type：	Control Circuit Board
Manufacture:	ABB	Condition：	Brand New
Range of Product:	ABB	Lead time：	In Stock
Weight:	2.1 kg	HS CODE：	8537101190
Dimension:	31.5x26x6cm	MOQ:	1
Product Origin:	SWEDEN	System：	DCS
Discontinued on:	Active	Communication Service:	Ethernet router

SDCS-CON-H01 3ADT320000R1501 Functional Description

The ABB 320000R1501 Control Circuit Board is a microprocessor-based control module designed for ABB DCS800 drive systems, delivering precise motor control and system monitoring. This module operates on +5V and +12V power inputs with a typical current consumption under 2A, ensuring efficient energy use while maintaining robust performance. The ABB Control Circuit Board 3ADT320000R1501 supports RS-232/RS-485 communication, enabling seamless integration with industrial networks for real-time data exchange and control.

The SDCS-CON-H01 3ADT320000R1501 ABB PDF features a dual-channel redundant design to minimize downtime in critical applications. Its operating temperature range of 0°C to 50°C and humidity tolerance of 5% to 85% (non-condensing) make it suitable for diverse industrial environments. The module’s storage temperature range (-20°C to 70°C) ensures durability during transportation and inactive periods.

The DC Speed Controller Motherboard ABB SDCS-CON-H01 excels in applications requiring high precision, such as metal processing, cranes, and mining equipment. Its advanced diagnostics and fault detection capabilities enhance system reliability, while its compact design simplifies installation in space-constrained control cabinets.

As a key component of ABB’s drive systems, the SDCS-CON-H01 3ADT320000R1501 Main Board ABB combines cutting-edge technology with rugged construction. Its MODBUS compatibility and robust performance make it indispensable for modern industrial automation, ensuring optimal efficiency and longevity in demanding operational conditions.
