ABB 3BHL000986P3012 5SDD2545L0001 IGCT Module

Inquiry now

3BHL000986P3012 5SDD2545L0001 Product datasheet

Model number:	3BHL000986P3012 5SDD2545L0001	Module Type：	IGCT Module
Manufacture:	ABB	Condition：	Brand New
Range of Product:	Advant OCS/800xA	Lead time：	In Stock
Weight:	2.56 kg	HS CODE：	8537101190
Dimension:	35x29x6.5cm	MOQ:	1
Product Origin:	SWEDEN	System：	DCS
Discontinued on:	Active	Communication Service:	Ethernet router

3BHL000986P3012 5SDD2545L0001 Functional Description

The ABB 3BHL000986P3012 5SDD2545L0001 IGCT Module is a premium Integrated Gate-Commutated Thyristor (IGCT) module designed for critical power applications. With a nominal voltage of 4500V and on-state current of 2500A, this module excels in HVDC transmission, FACTS systems, and industrial drives. Its fast switching (1.5μs turn-on/off) and low conduction losses (2.5V drop) ensure optimal efficiency in high-power conversion systems.

The IGCT Module 5SDD2545L0001 ABB delivers exceptional surge handling with a peak current of 25kA (1ms) and critical di/dt of 800A/μs, making it ideal for transient-heavy environments. Its blocking voltage of 4500V (VDRM/VRRM) and gate trigger voltage (1.5–2.5V) ensure reliable operation under demanding conditions. The integrated gate drive simplifies installation while enhancing system reliability.

Engineered for harsh industrial settings, the ACS6000 DIODE 5SDD2545L0001 MVAC Drives Parts operates within a wide temperature range (–40°C to +125°C) and features high surge current tolerance. Its compact design (35×29×6.5 cm, 2.56 kg) and low leakage current (10mA) minimize energy waste, while the non-repetitive blocking voltage (4500V) ensures fault resilience.

The 3BHL000986P3012 DIODE 5SDD2545L0001 ACS6000 is widely used in medium-voltage drives, renewable energy systems, and grid stabilization projects. Manufactured in Sweden and shipped globally (HS Code: 8537101190), it meets stringent industry standards. This Advant DCS 800xA ABB 3BHL000986P3012 5SDD2545L0001 combines high power density, thermal stability, and long-term reliability, making it a top choice for modern power infrastructure.
