Competitive Advantage

• High-Temperature Resistance: Engineered to operate reliably in harsh environments from -29°C up to +204°C (+400°F).
• Self-Generating Design: Utilizes moving-coil technology which generates its own voltage signal and eliminates external power needs.
• Impulsive Shock Immunity: Inherently less sensitive to sudden impacts or impulsive excitation compared to solid-state alternatives.
• Flexible Interconnection: Features a top-mounted connector profile that simplifies routing in tight structural areas.

System Compatibility and Alternative Models

System Compatibility

• Interfaces directly with Bently Nevada 3300 or 3500 machinery protection monitors.
• Supports standard two-wire interconnecting cables up to 305 meters (1,000 feet) before experiencing frequency roll-off.

Alternative Models & Differences

• 9200-01-01-10-00: Standard temperature version rated up to +121°C instead of the high-temperature +204°C rating of the 74712.
• 74712-03-10-02-00: Designed for a 90° horizontal mounting orientation instead of the 0° vertical mounting.
• 74712-01-11-02-00: Features an electrically isolated M10x1 circular base to mitigate electrical ground loops.

Ordering Information Table

Installation & Troubleshooting FAQ

Q1: What is the significance of the 01 mounting angle option during field setup?

A: The 01 option specifies a vertical orientation (0° ±2.5°). Mounting the transducer beyond this threshold alters its internal alignment and invalidates the factory sensitivity calibration.

Q2: Why does the velocity transducer output generate a false vibration signal?

A: Loose mounting base contact or insufficient torque can cause mechanical looseness. Ensure the M10x1 stud is securely torqued to 5.6 N·m (50 in·lb) to maximize frequency response.

Q3: Can an integral hardline cable be added to this specific high-temperature transducer model?

A: No, integral hardline cable options are exclusively available for the 9200 standard temperature family and cannot be ordered with the 74712.
